TRS100 precision tilt rotary stages
1.The stage providesthree dimensional tilt and rotation adjustment.
2.Driven with M6×0.25 fine thread screws.
3.High quality disk reset spring.
4.Elastic clamping
- description
- parameters
|
Model |
TRS101 |
|
|
Table size （mm） |
Φ48 |
|
|
Adjusting range of tilt |
θx |
7° |
|
θy |
||
|
Adjusting range of rotation |
θz |
7.5° |
|
Weight （kg） |
0.35 |
|
