TMS110 series multi-axis positioning stages
1.Actuated
withcrossroller bearing guides, allowing forreliable movement and high precision.
2.Driven withmicrometer head.
3.Resetspringeliminates return backlash.
4.Separate models are available for right-hand
and left-hand use.
- description
- parameters
|
Model |
TMS111M |
TMS112M |
|
Axles |
XY two axles |
XYZ three axles |
|
Travel （mm） |
13 |
|
|
Driving |
micrometer head |
|
|
Minimum reading（mm） |
0.01 |
|
|
Resolution（mm） |
0.002 |
|
|
Error of swing |
＜22″ |
|
|
Loading capacity (kg) |
5 |
2.5 |
|
Weight （kg） |
0.75 |
1.15 |
