BS100 series beam steeper
1. Can applied multiple diameters of plane mirror
2. Driving by M6×0.25 fine thread screw
3. High quality dished spring reset
4. Mirror mounts can rotation
5. Tilt adjustment by double axis
- description
- parameters
|
Model |
BS101 |
BS102 |
BS103 |
|
|
Lifting height for beam（mm） |
180 |
|||
|
Adjusting range of tilt |
θx |
±4° |
||
|
θy |
±4° |
|||
|
Rotation angle of mirror mounts |
θz |
360° |
||
|
A Applied diameter |
20 |
25 |
30 |
|
|
B |
32 |
32 |
36 |
|
|
Weight（kg） |
0.7 |
0.7 |
0.7 |
|
