OA100 series micrometers
Used for quantitative adjustment
1. Minimum graduations:0.01mm
2. Resolution:0.002mm
- description
- parameters
|
Model |
OA101 |
OA102 |
OA103 |
OA104 |
OA105 |
OA106 |
|
|
Travel |
6 |
13 |
25 |
||||
|
A |
MIN |
1.5 |
4 |
2.5 |
|||
|
MAX |
7.5 |
17 |
27.5 |
||||
|
B |
6 |
9.5 |
16.5 |
||||
|
C |
37 |
58.5 |
110 |
||||
|
D |
Φ3.5 |
Φ6 |
Φ9.4 |
||||
|
E |
Φ6 |
Φ9.5 |
Φ11 |
||||
|
F |
Φ9.4 |
Φ13 |
Φ18 |
||||
|
Comment |
Ball head |
Flat head |
Ball head |
Flat head |
Flat head |
Ball head |
|
